Color Galvanized Steel Insulated Sandwich Panel
Advanced building material offering pitch 205mm and panel length up to 12 meters, designed for superior building envelope solutions with excellent insulation, durability, and fire resistance.
Product Overview
The Structural Insulated Sandwich Panel is engineered to meet the highest standards of insulation, durability, and fire resistance. This versatile panel serves as an ideal solution for various construction applications including walls, roofs, and facades, contributing significantly to energy efficiency and building comfort.
Key Features
- Product Name: Insulated Sandwich Panel
- Material: Color Galvanized Steel Sheet
- Foam Thickness Options: 30mm, 40mm, 50mm
- Type: Roof Panel EPS
- Steel Plate Thickness: 0.3-0.6mm
- Panel Width Range: 1000mm - 1200mm
- Metal Faced Sandwich Panel for enhanced durability
- Structural Insulated Sandwich Panel providing excellent strength
- Composite Insulated Sandwich Panel offering superior thermal performance
Technical Specifications
| Parameter |
Specification |
| Purpose |
Decorative Finishing |
| Fire Class |
B15 |
| Steel Plate Thickness |
0.3-0.6mm |
| Fire Resistance |
Class A1 To B2 (depending on core material) |
| Panel Width |
1000mm - 1200mm |
| Steel Sheet Material |
Color Galvanized Steel |
| Advantage |
Heat Insulation, Sound Insulation |
| EPS Thickness |
50-150mm |
| Panel Thickness |
30mm - 200mm |
| Foam Thickness |
30mm/40mm/50mm |
Applications
Wenchen Insulated Sandwich Panels are versatile construction materials suitable for roofing systems, cold storage facilities, warehouses, factories, agricultural buildings, modular construction, temporary structures, exhibition halls, and cold rooms. Available in a wide range of RAL color options for customizable decorative finishing.
Customization Options
Wenchen offers customized Insulated Wall Sandwich Panel solutions with panel widths ranging from 1000mm to 1200mm and panel thickness customizable from 30mm up to 200mm. Panel length options extend up to 12 meters to accommodate different architectural designs and installation preferences.
Support & Services
Our comprehensive support includes technical assistance, installation guidance, customized panel fabrication, on-site consultation, and after-sales support. We provide training sessions for installers and warranty coverage with detailed product information for quality assurance.
Packaging & Shipping
Each panel is carefully packaged with waterproof and anti-dust materials, supported by wooden crates or steel frames for international shipments. Corner protectors and padding ensure safe transit, with custom packaging options available upon request.
Frequently Asked Questions
What is the Insulated Sandwich Panel made of?
The Wenchen Insulated Sandwich Panel consists of two outer metal sheets with an insulating core material in between, providing excellent thermal insulation and structural strength.
Where is the Wenchen Insulated Sandwich Panel manufactured?
The Wenchen Insulated Sandwich Panel is manufactured in China, ensuring high-quality production standards and reliable supply.
What are the typical applications of Wenchen Insulated Sandwich Panels?
These panels are widely used in construction for walls, roofs, cold storage facilities, clean rooms, and other areas requiring thermal insulation and durability.
How does the insulation core affect the performance of the sandwich panel?
The insulation core significantly enhances thermal efficiency, reduces energy consumption, and provides soundproofing, making the panels ideal for temperature-sensitive environments.
Can Wenchen Insulated Sandwich Panels be customized in size and thickness?
Yes, Wenchen offers customization options for the panels, including various sizes, thicknesses, and core materials to meet specific project requirements.
Product Images
